| Nomor bagian : | EEE-FT1E330AR |
|---|---|
| Pabrikan / Merek : | Panasonic |
| Deskripsi : | CAP ALUM 33UF 20% 25V SMD |
| Status RoHs : | Memimpin bebas / RoHS Compliant |
| Jumlah yang tersedia | 437064 pcs |
| Lembar data | 1.EEE-FT1E330AR.pdf2.EEE-FT1E330AR.pdf3.EEE-FT1E330AR.pdf4.EEE-FT1E330AR.pdf5.EEE-FT1E330AR.pdf |
| Tegangan - Nilai | 25V |
| Toleransi | ±20% |
| Permukaan Luas Gunung Tanah | 0.169" L x 0.169" W (4.30mm x 4.30mm) |
| Ukuran / Dimensi | 0.157" Dia (4.00mm) |
| Seri | FT |
| Ripple Current @ Low Frequency | 104mA @ 120Hz |
| Ripple Current @ High Frequency | 160mA @ 100kHz |
| penilaian | AEC-Q200 |
| Polarisasi | Polar |
| Pengemasan | Tape & Reel (TR) |
| Paket / Case | Radial, Can - SMD |
| Nama lain | EEEFT1E330AR PCE5004TR |
| Suhu Operasional | -55°C ~ 105°C |
| mount Jenis | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 19 Weeks |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| memimpin Spasi | - |
| Status Gratis Memimpin / Status RoHS | Lead free / RoHS Compliant |
| Tinggi - Duduk (Max) | 0.240" (6.10mm) |
| ESR (Resistance Series Equivalent) | 850 mOhm @ 100kHz |
| Detil Deskripsi | 33µF 25V Aluminum Electrolytic Capacitors Radial, Can - SMD 850 mOhm @ 100kHz 2000 Hrs @ 105°C |
| kapasitansi | 33µF |
| Aplikasi | Automotive |
Panasonic
