| Nomor bagian : | EEU-FC1H222C |
|---|---|
| Pabrikan / Merek : | Panasonic |
| Deskripsi : | CAP ALUM 2200UF 20% 50V RADIAL |
| Status RoHs : | Memimpin bebas / RoHS Compliant |
| Jumlah yang tersedia | 33959 pcs |
| Lembar data | EEU-FC1H222C.pdf |
| Tegangan - Nilai | 50V |
| Toleransi | ±20% |
| Permukaan Luas Gunung Tanah | - |
| Ukuran / Dimensi | 0.709" Dia (18.00mm) |
| Seri | FC |
| Ripple Current @ Low Frequency | 2.48A @ 120Hz |
| penilaian | AEC-Q200 |
| Polarisasi | Polar |
| Pengemasan | Bulk |
| Paket / Case | Radial, Can |
| Nama lain | EEU-FC1H222C-ND EEUFC1H222C P19488 |
| Suhu Operasional | -55°C ~ 105°C |
| mount Jenis | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 15 Weeks |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| memimpin Spasi | - |
| Status Gratis Memimpin / Status RoHS | Lead free / RoHS Compliant |
| impedansi | 23 mOhms |
| Tinggi - Duduk (Max) | 1.476" (37.50mm) |
| ESR (Resistance Series Equivalent) | - |
| Detil Deskripsi | 2200µF 50V Aluminum Electrolytic Capacitors Radial, Can 5000 Hrs @ 105°C |
| kapasitansi | 2200µF |
| Aplikasi | Automotive |
Panasonic
